OneRugged V80J Linux Vehicle PC
The OneRugged V80J Linux shares the same 8-inch in-vehicle hardware platform as the V80J, equipped with an Intel® 11th Gen Celeron® N5100 processor, but runs a Linux operating system. Integrated WiFi 5, 4G LTE and GPS support available vehicle mushroom antennas, and the unit has passed dustproof, waterproof, anti-vibration and wide-temperature tests, with M12 aviation plugs and VESA/RAM mounting suited to forklifts, cranes and trucks.
- Display: 8″ IPS, 800×1280, 1000 nit
- Processor: Intel® Celeron® N5100
- OS: Linux
- Memory: 8GB RAM / 128GB eMMC
- Connectivity: WiFi (2.4G+5G), optional 4G, Bluetooth 5.0, GPS+GLONASS
- Power: M12-8 power port, optional 9–36V wide-voltage module
- Mounting: VESA and RAM standard options
- Rugged rating: IP65
- Weight: approx. 620g
Tech specs
Dimensions
218.1×154.5×23.0mm
Weight
620g
Product Color
Black
Display
Size: 8 inch 16:10, Resolution: 800*1280 IPS, Brightness: 1000cd/㎡
Touch Panel
5-point tempered glass capacitive screen G+G, hardness 7H
Ports
Optional: SIM card slot *1
USB 3.0 *1
M12-8 Power port *1 (Compatible: DC power port, suitable for cigarette lighter)
Optional: M12-12 Aviation port 1 *1 (Compatible: 1000M Ethernet port)
Optional: M12-12 Aviation port 2 *1 (Compatible: RS232 port or RS485 port)
Optional: M12-12 Aviation port 3 *1 (Compatible: USB 2.0 port or CAN port or CVBS port)
Processor
Intel® Celeron® Processor N5100
Operating System
Linux
Memory+Storage
RAM: 8GB (LPDDR3)ROM: 128GB (EMMC)
Battery (optional)
Built in polymer lithium ion battery, 1000mAh/7.4V
RTC Battery
Built in RTC battery
Power
Power adapter cable (M12-8 power port to φ5.5 power port)Optional: φ5.5 adapter (input AC 100V~240V 50Hz/60Hz, output DC 19V/3.42A)
WiFi
802.11 (a/b/g/n/ac), 2.4G+5.8G dual frequencyStandard WiFi rod antenna
WAN (optional)
4GOptional 4G rod antenna
Bluetooth
Bluetooth 5.0
GNSS
GPS+GLONASS, optional BeidouStandard GPS rod antenna
NFC (optional)
Support
IP Ratings
IP65
Temperature
Working temperature: -20 °C to 60 °CStorage temperature: -30 °C to 70 °C
ESD Protection
±15kV air discharge±8kV contact discharge
Standard
WIFI rod antenna
GPS rod antenna
Power adapter cable (M12-8 power port to φ5.5 power port, suitable for cigarette lighter)
Optional
4G rod antenna
Cigarette lighter adapter
φ5.5 power adapter
Power adapter cable (M12-8 power port to 4 loose wires)
9V-36V wide voltage module
VESA standard
RAM standard
Function adapter cable (M12-12 aviation port to USB 2.0 *2 + CAN *1)
Function adapter cable (M12-12 aviation port to RS232 *1 + RS485 *1)
Function adapter cable (M12-12 aviation port to RS232 *2)
Function adapter cable (M12-12 aviation port to 1000M RJ45 *1)
Function adapter cable (M12-12 aviation port to 12 loose wires)GPS vehicle mushroom antenna
